Features:
The HDMI to HD/SD/3G SDI conveter clamp allows you convert HDMI signal to SDI signal when you field shoot,, it can be powered up by Sony NP-FM50, NP-F330 NP-F530\F550\F570 NP-F730\F750\F770 NP-F930\F950\F960\F970
It comes with a 15mm rod Cheese clamp, allows you attach it on to you 15mm rod support system DSLR RIG or RIG cage.
It also allows you to power up your converter with more power supply ( 4.85V-18V ): power bank, F970/F550 battery, brick battery, AC adapter, USB ...
It with a Power LED and a signal Lock LED
SDI compatible with: 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s
HDMI Compatible with:480i@59.94, 576i, 720p@50/59.94/60, 1080i@50/59.94/60, 1080p@23.98/24/25/29.97/30/50/59.94/60.
Please note:
480i/576i to SD-SDI (SMPTE 259M-C, 270 Mbit/s)
720P/1080i to HD-SDI (SMPTE 292M, 1.485 Gbit/s or 1.485/1.001 Gbit/s)
1080P to 3G-SDI (SMPTE 424M/425M-AB, 2.970 Gbit/s and 2.970/1.001 Gbit/s)
* 480P/576P HDMI Can not be converted to SD-SDI.
Specification:
* Name: HDMI to SDI Converter Clamp SD-SDI HD-SDI 3G-SDI Adapter fr 15mm Rod Support RIG Cage
* Input: HDMI signal
* Output: HD-SDI / 3G-SDI
* Max Current: 500mA
* AC adapter: 100-240V 50-60Hz output 5V 1A
* Working Voltage: 4.85V-18V
* Working Temperature: -15 to 55 闁?
* Dimension: 95mm X 65mm X 45mm
* N/W: 159g
Package contains:
1 piece of HDMI to SDI Converter Clamp
1 piece of Adapter
1 piece of USB to DC cable
* battery is not included.
